Mechanical Seal T120 cartridge-balanced design locks faces for zero leak at 16 bar, 180 °C; each Mechanical Seal T120 pairs 316SS and carbon-graphite, giving Carbon T120 Mechanical Seal outstanding chemical and abrasion resistance. T120 Mechanical Seal fits ANSI/DIN bores 18-80 mm, letting Carbon T120 Mechanical Seal retrofit centrifugal, chemical and HVAC pumps in minutes. Install T120 Mechanical Seal to cut MTBR 35 %—because Mechanical Seal T120 proves T120 Mechanical Seal and Carbon T120 Mechanical Seal outclass standard seals.
Operational Conditions:
Temperature: -40℃ to +200℃
Pressure: ≤1.0MPa
Speed: ≤15m/s
Materials:
Stationary Ring: Silicon Carbide, TC, SUS304
Rotary Ring: Silicon Carbide, CAR, TC
Secondary Seal: NBR, EPDM, Viton
Spring and Metal Parts: SUS304,SUS316
Applications:
Clean water,
sewage water
oil and other moderately corrosive fluids
Stationary Seat:
Standard:
Alternative:
