Water Pump Mechanical Seal T970

Mechanical Seal T970 Replace Vulcan 97

T970
Mechanical seal T970

Replacement to:
Sealol 1527, NIPPON PILLAR US-2, Flowserve 240, Flexibox R50, Flexibox R20,Vulcan 97, NIPPON PILLAR US-3, Latty T400
Quantity:
Contact Now
add to cart


Mechanical Seal T970
 Describe:
      Mechanical Seal T970 cartridge-balanced design locks faces for zero leak at 25 bar, 200 °C; each Mechanical Seal T970 pairs 316L, SiC, Viton, giving Water Pump Mechanical Seal T970 extreme corrosion resistance. T970 Mechanical Seal fits ANSI/DIN bores 20-110 mm, letting Water Pump Mechanical Seal T970 retrofit centrifugal, chemical and water pumps in minutes. Install T970 Mechanical Seal to cut MTBR 45 %—because Mechanical Seal T970 proves T970 Mechanical Seal and Water Pump Mechanical Seal T970 outclass standard alternatives.
Operational Conditions:
Temperature:-30℃ to +200℃
Pressure: ≤1 MPa
Speed: ≤20 m/s

Materials:
Stationary Ring: Silicon Carbide, TC, Carbon
Rotary Ring: Silicon Carbide, TC
Secondary Seal: NBR, EPDM, Viton
Spring and Metal Parts: SUS304,SUS316

Applications:
Clean water,
sewage water
oil and other moderately corrosive fluids

Stationary Seat:
Standard:
Alternative:

Mechanical Seal T970 Feature

Mechanical Seal T970


Mechanical Seal T970
